The NSE USB HD Endoscopic Camera System is a lightweight, portable, and high-performance imaging solution designed for ENT, outpatient, and minimally invasive procedures.
Unlike bulky traditional systems, this compact device integrates illumination and imaging into a single handheld unit, ensuring mobility, efficiency, and crystal-clear visualization.
Simply connect to any computer with a USB 3.0 port to achieve HD video recording, examination, and real-time broadcasting.
Key Features
Extremely High Definition Imaging
Full HD imaging (1920×1080, 30fps)
Crystal-clear endoscopic detail
Optional global shutter sensor for stroboscopy
Highly Integrated & Portable
Light source integrated in the handle
Plug-and-play via USB 3.0
Lightweight, handheld design (200g)
Waterproof & Sterilizable
IP58 dust & waterproof standard
Immersion up to 1m for 1 hour
Compatible with soaking, plasma & glutaraldehyde sterilization
User-Friendly Controls
Snapshot, Record, Freeze, Zoom In/Out
5-level light intensity adjustment
White balance control
Technical Specifications
Image Sensor CMOS (Rolling shutter or optional Global shutter)
Resolution 1920×1080 (Full HD), 30 fps
Interface USB 3.0 (USB Type-C optional)
Optical Interface C-Mount for standard adapters
Weight 200g
Waterproof Level IP58
Software MedCam – Patient management, reporting, DICOM compatible
OS Compatibility Windows 7/8/10 & macOS Catalina
Compatibility
Regular optical adapters (F18mm ~ F35mm)
Olympus & Pentax adapters (F18mm ~ F35mm)
Karl Storz adapters with zoom (F15mm ~ F25mm or more)
Integrated LED Light Source
5W LED, detachable yet waterproof
Max intensity: 282,000 lux
Color temperature: 5700K
Lifetime: 20,000 hrs
Cable length: 500 mm
Secure clasp connection
Software (MedCam)
Patient management system
Report output
DICOM compatible
Multi-language (10 languages)
Compatible with Windows & Mac OS X
Computer Requirements
Basic Configuration
USB 3.0 port
Windows 7/8/10 or macOS Catalina
Intel i5 processor, 4 GB RAM
Ideal Configuration
USB 3.0 port
Windows 7/8/10 or macOS Catalina
Intel i7 processor, 8 GB RAM
Full HD screen (1920×1080)
Supplied By: Mastermed Equipment Trading LLC
